Intel® Socket 1151 for 8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® 處理器
支援 Intel® 14 nm CPU
支援 Intel® Turbo Boost 技術2.0

*有關支援的 CPU 型號資訊，請參閱 tw.asus.com 網站內容。
* 是否支援 Intel® Turbo Boost Technology 2.0，需視 CPU 類型而定。

Intel® B360

4 x DIMM, 最高可支援到64GB, DDR4 2666/2400/2133 MHz 非ECC, 無緩衝區 記憶體
Intel® B360 Chipset
雙通道 記憶體架構
支援 Intel® Extreme Memory Profile (XMP)
*有關記憶體合格廠商清單（QVL）的相關資訊，請參閱 www.asus.com 網站或本使用手冊。
* The maximum memory frequency supported varies by processor
** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.

Integrated Graphics Processor- Intel® HD Graphics support
支援多 VGA 輸出 : HDMI/DVI-D/RGB 連接埠
- 支援 DVI 最大解析度 1920 x 1200 @ 60 Hz
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
最大共享記憶體 1024 MB
支援 Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™

1 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0/2.0 x1

Intel® B360 Chipset :
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s埠, 灰色

Realtek® RTL8111H, 1 x Gigabit LAN
ASUS LAN Guard

Realtek® ALC887 8 通道 高傳真音效 CODEC
- 支援 : 插頭偵測, 前面板插孔指定功能
Audio Feature :
- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
* Choose the chassis with HD audio module in front panel to support 8-channel audio output.

Intel® B360 Chipset :
2 x USB 3.1 Gen 2 up to 10Gbps 連接埠 (2 位於背板, teal blue, Type-A)
Intel® B360 Chipset :
3 x USB 3.1 Gen 1 up to 5Gbps 連接埠 (1 位於背板, , 2 位於主機板中, USB Type-C™)
Intel® B360 Chipset :
6 x USB 2.0/1.1 連接埠 (2 位於背板, +黑色, 4 位於主機板中, Type-A)

華碩 EPU :
- EPU
ASUS 5X Protection III :
- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
- ASUS Overvoltage Protection: World-class circuit-protecting power design
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- ASUS DIGI+ VRM: 5 Phase digital power design
ASUS OptiMem：
- Optimem (Improved DDR4 stability)
華碩獨家功能 :
- AI Suite 3
- Ai Charger
- PC Cleaner
- File Transfer
華碩靜音散熱解決方案 :
- 風格獨特的無風扇設計 - 散熱解決方案
- ASUS Fan Xpert 2+
華碩 EZ DIY :
- 華碩 CrashFree BIOS 3
- 華碩 EZ Flash 3
- ASUS UEFI BIOS EZ Mode
華碩 Q-Design :
- 華碩 Q-DIMM
M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)

1 x PS/2 鍵盤(紫)
1 x PS/2 滑鼠(綠)
1 x DVI-D
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) 連接埠
2 x USB 3.1 Gen 2 (teal blue)Type-A, up to 10Gbps
1 x USB 3.1 Gen 1 USB Type-C™, up to 5Gbps
2 x USB 2.0
1 x 8-channel Audio I/O

1 x USB 3.0 接頭支援額外的 2 USB 3.0 連接埠 (19-pin)
2 x USB 2.0 接頭支援額外的 4 USB 2.0 連接埠
1 x COM 接頭連接埠
6 x SATA 6Gb/s 接頭
1 x CPU 風扇接頭
2 x 機殼風扇接頭
1 x Aura RGB Strip Header
1 x S/PDIF 輸出接頭
1 x 24-pin EATX 電源接頭
1 x 前面板音訊接頭 (AAFP)
2 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices
1 x TPM header
1 x LPT header
1 x Clear CMOS 跳線
1 x 8-pin EATX 12V Power connectors
1 x System panel connector
1 x Chassis intrusion header
1 x Speaker connector

使用者手冊
I/O 擋板
2 x Serial ATA 6.0Gb/s 纜線
2 x M.2 screws

128Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F3 My Favorites, Last Modified log, F4 AURA ON/OFF, F6 Qfan Control, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial
Presence Detect) memory information

WOL by PME, PXE

Windows® 10 64-bit

mATX 主機板尺寸
9.6 吋 x 8.1 吋 ( 24.4 公分 x 20.6 公分 )
