| Model Number | RS-550-ACAA-B3 |
| Type | Intel Form Factor ATX 12V V2.31 |
| Dimensions | 150 x 140 x 86mm / 5.9 x 5.5 x 3.4 inch |
| Input Voltage | 100-240Vac |
| Input Range | Full range |
| Input Frequency Range | 60-50Hz |
| PFC | Active PFC (>0.9 typical) |
| Power Good Signal | 100-500ms |
| Hold Up Time | >16ms |
| Efficiency | 85% @ Typical Load |
| MTBF | >100,000 Hours |
| Protection | OVP/UVP/OPP/OTP/OCP/SCP |
| Quality Certificates | CE/FCC/UL/TUV/RCM/EAC/BSMI/CCC |
| Connectors | - 20+4 Pin MB x 1 - 4+4 Pin CPU + 12V x 1 - 6+2 Pin PCI-e x 2 - SATA x 6 - 4 Pin Peripheral x 3 - 4 Pin Floppy x 1 |
|
保固
|
原廠五年保固 |
|
(生產測試、研發測試等非正常使用，不在保固範圍內，一經拆封.恕不退換)
|
|
