| 型號 | RR-212X-20PM-R1 |
| CPU 插座 | Intel LGA 2011/1366/1156/1155/1150/775 AMD FM1/AM3+/AM3/AM2+/AM2 |
| 尺寸 | 120 x 79 x 158 mm / 4.7 x 3.1 x 6.2 inch |
| 散熱器尺寸 | 116 x 51 x 158 mm / 4.6 x 2.0 x 6.2 inch |
| 散熱器材質 | 4 Direct contact heatpipes / Aluminum fins |
| 散熱器重量 | 492g / 1.1lbs |
| 熱導管尺寸 | ø6mm |
| 風扇尺寸 | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
| 風扇轉速 | 600 - 2,000 RPM (PWM) ± 10% |
| 風扇風流 | 24.9 - 82.9 CFM ± 10% |
| 風扇氣壓 | 0. 3 - 2.09 mm H2O ± 10% |
| 風扇平均壽命 | 160,000 hrs |
| 風扇噪音等級 | 9 - 36 dBA |
| 軸承類型 | 4th Generation Bearing |
| 接頭 | 4-Pin |
| 額定電壓 | 12 VDC |
| 額定電流 | 0.37A |
| 耗電量 | 4.44W (max) |
| 風扇重量 | 106g / 0.2lbs |
